SKU: BCSG-EZ-CG2420
Includes
1 x EIZO ColorEdge CG2420 LCD Monitor 1 x DisplayPort Cable (2m) 1 x HDMI Cable (2m) 1 x AC Power Cord 1 x USB Cable 1 x Setup Guide 1 x EIZO LCD Utility Disk (ColorNavigator Software and PDF User Manual), 1 x Adjustment Certificate, 1 x Screen Cleaner, 1 x Monitor Hood, 1 x Quick Reference
EIZO ColorEdge CG2420 24.1″ ( 61.1 cm) Hardware Calibration LCD Monitor
Original price was: $2,691.00.$2,599.00Current price is: $2,599.00.
Hassle-free maintenance and optimal color reproduction for professionals to express their vision.
Let your imagination soar with this professional-level model for use in photography, design, print, and post production. It features a built-in self calibration sensor for hassle-free monitor maintenance, vivid colors reproduced to industry standards, and exceptionally high contrast for producing true blacks.
Features:
- Wide gamut LCD with LED technology, contrast 1,500:1, brightness 400 cd/m²
- 99% Adobe RGB and 98% DCI-P3 color range
- Integrated measurement device and fully automatic self-calibration
- Precise hardware calibration of brightness, white balance, and gamma
- Digital Uniformity Equalizer for perfect luminance distribution and color purity
- Color precision with 16-bit look-up-table and up to 10-bit color reproduction
- Temperature-controlled adjustment of color drift and brightness
- DisplayPort, DVI-D, and HDMI ports
- ColorNavigator calibration software and light protection shields included in delivery
- More details: Download Brochure
| Model Variations | CG2420-BK |
|---|---|
| Panel | |
| Type | IPS |
| Backlight | Wide-Gamut LED |
| Size | 24.1" / 61.1 cm |
| Native Resolution | 1920 x 1200 (16:10 aspect ratio) |
| Viewable Image Size (H x V) | 518.4 x 324.0 mm |
| Pixel Pitch | 0.270 x 0.270 mm |
| Pixel Density | 94ppi |
| Display Colors | DisplayPort, HDMI: 1.07 billion from a palette of 278 trillion DVI: 16.77 million from a palette of 278 trillion |
| Viewing Angles (H / V, typical) | 178°, 178° |
| Brightness (typical) | 400 cd/m2 |
| Recommended Brightness for Calibration | 120 cd/m2 or less |
| Contrast Ratio (typical) | 1500:1 |
| Response Time (typical) | 10 ms (gray-to-gray) |
| Color Gamut (typical) | Adobe RGB: 99%, DCI-P3: 98% |
| Video Signals | |
| Input Terminals | DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 1.4), DVI-D (HDCP 1.4) |
| Digital Scanning Frequency (H / V) | DisplayPort, DVI: 26 - 78 kHz, 24 - 61 Hz HDMI: 15 - 78 kHz, 24 - 61 Hz |
| USB | |
| Upstream | USB 3.1 Gen 1: Type-B |
| Downstream | USB 3.1 Gen 1: Type-A x 3 (Battery Charging 10.5 W max. x1) |
| Power | |
| Power Requirements | AC 100 - 240 V, 50 / 60 Hz |
| Typical Power Consumption | 20W |
| Maximum Power Consumption | 79W |
| Power Save Mode | 0.7W or less |
| Built-in Calibration Sensor | Yes |
| Features & Functions | |
| Brightness Stabilization | Yes |
| Digital Uniformity Equalizer | Yes |
| Preset Modes | Custom, Adobe RGB, sRGB, Calibration |
| OSD Languages | English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| Others | Color Adjustment, SelfCalibration, Input Color Format, Input Range, Noise Reduction, I/P Conversion, Picture Expansion, Menu Rotation, Power Save, Input Skip, Mode Skip, Key Lock, DUE Priority |
| Physical Specifications | |
| Dimensions (Landscape, W x H x D) | 554.4 x 396 - 551 x 245 mm |
| Dimensions (Without Stand, W x H x D) | 554.4 x 362 x 64 mm |
| Dimensions (Landscape with Hood, W x H x D) | 572.4 x 405 - 560 x 336 mm |
| Net Weight | 7.8 kg / 17.2 lbs |
| Net Weight (Without Stand) | 5.0 kg / 11.0 lbs |
| Net Weight (With Hood) | 8.5 kg / 18.7 lbs |
| Height Adjustment Range | 155 mm |
| Tilt | 35° Up, 5° Down |
| Swivel | 344° |
| Pivot | 90° |
| Hole Spacing (VESA Standard) | 100 x 100 mm |
| Environmental Requirements | |
| Operating Temperature | 0 - 35°C |
| Operating Humidity (R.H., non condensing) | 20 - 80% |
| Certifications & Standards (Please contact EIZO for the latest information.) | CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics, TUV/Color Accuracy (Quick Stability), FograCert Softproofing System (class A) |
| Dedicated Software | |
| Easy Screen-to-Print Color Matching Tool Quick Color Match | Supported |
| Proprietary Software | |
| Color Management Software ColorNavigator 7 | Supported |
| Color Management Software ColorNavigator 6 | Supported |
| Dedicated Software | |
| Monitor Management Software ColorNavigator NX | Supported |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) | |
| Signal Cables | DisplayPort (2 m), HDMI (2 m) |
| Others | AC power cord, USB Type-A - USB Type-B cable (2 m), Setup guide, Adjustment certificate, ScreenCleaner, Monitor hood, Quick reference, Warranty card, VESA mounting screw x 4 |
| Warranty | Five Years 2 5 Zero bright sub-pixels for six months from date of purchase |
| Dimension Drawing |
- 2 With current LCD / OLED technology, a panel may contain a limited number of missing or flickering pixels.
- 5 If the monitor is left on continuously over a long period of time, dark smudges or burn-in may appear. To maximize the life of the monitor, we recommend the monitor be turned off periodically.
